Home»Automation»PowerCLI: Get Storage Paths of ESXi servers from vCenter
Automation

PowerCLI: Get Storage Paths of ESXi servers from vCenter

Catalin CristescuBy Catalin CristescuJuly 18, 2023
Share Facebook Twitter Pinterest LinkedIn Tumblr Reddit Telegram Email
Share
Facebook Twitter LinkedIn Pinterest Email

I needed to make an automated script to get all the Storage paths for all ESXi servers. To be noted that the script will retrieve only the ESXis with VMFS datastores and collect the information.

Script

# Retrieve vCenter, ESXi, cluster, and datastore information
$vcu = ""

Connect-VIServer -Server $vcu

$vCenterInfo = $vcu
$esxiHosts = Get-VMHost | Where-Object {
    $datasto = $_ | Get-Datastore
    $datasto | ForEach-Object { $_.ExtensionData.Summary.Type -ne "NFS" }
}
$clusters = Get-Cluster
$datastores = Get-Datastore

$results = @()

foreach ($esxiHost in $esxiHosts) {

    $hbaInfo = Get-VMHostHba -VMHost $esxiHost

    foreach ($hba in $hbaInfo) {

        $paths = Get-ScsiLun -Hba $hba

        foreach ($path in $paths) {

            $VMHostScsiLunPaths = $path | Get-ScsiLunPath


            foreach ($scsiPath in $VMHostScsiLunPaths) {
                $datastore = $datastores | ? {$_.ExtensionData.Info.Vmfs.Extent[0].DiskName -eq $path.canonicalName}

                $property = [ordered]@{
                    "vCenter" = $vCenterInfo
                    "ESXi" = $esxiHost.Name
                    "Cluster" = $esxiHost.Parent.Name
                    "Datastore" = $datastore.Name
                    "DatastoreType" = $datastore.ExtensionData.Summary.Type
                    "CanonicalName" = $path.CanonicalName
                    "PathPolicy" = $path.Multipathpolicy
                    "LUN" = (($path.RunTimeName -Split "L")[1] -as [Int])
                    "HBA" = $hba.Device
                    "Source" = "{0}" -f ((("{0:x}" -f $hba.PortWorldWideName) -split '([a-f0-9]{2})' | where {$_}) -Join ":")
                    "HBAname" = $path.RunTimeName
                    "Status" = $scsiPath.State
                    "Target" = $scsiPath.SanID
                    "Path" = $scsiPath.Name
                    "PathState" = $scsiPath.ExtensionData.PathState
                }

                # Add the object to the results array
                $results += New-Object -TypeName psobject -Property $property
            }
        }
    }
}
$results | Export-Csv -Path "C:\temp\output.csv" -NoTypeInformation

Disconnect-VIServer -Server $vcu -Confirm:$false
nfs paths powercli powershell storage vmfs
